EnerNova Charger
1 / 5
This 22kW Home Smart Type 2 EV Charger is a high-efficiency charging solution engineered for residential electric vehicle use, boasting universal Type 2 connector compatibility to match most mainstream EV models on the market. Delivering a powerful 22kW output with ≤32A current, it enables fast and stable charging to significantly cut down charging time for daily commuting and travel needs.
Built with an IP55 waterproof and dustproof rating, the charger features a rugged plastic enclosure, making it suitable for both indoor and outdoor installation with reliable performance against harsh environmental conditions. It comes equipped with a 4.3-inch color touch screen for intuitive operation, and supports smart control via RFID card, mobile APP and energy meter for flexible charging management.
| Model NO. | T6 |
| Interfaces | One Pile with Multiple Charges |
| Installation | Portable |
| Charge Method | Quick Charge |
| Power | 3.5kw / 7kw |
| Material | PC9010 |
| Input Voltage | AC120V-240V |
| IP Class | IP 55 |
| Leakage Protection | Type A + C |
| Frequency | 50/60Hz |
| Color | Black / Silver |
| Origin | China |
| Classification | Item | Parameter |
|---|---|---|
| Input | Power supply | Single phase / 3 phase |
| Voltage | 120V-240V / 380V-400V | |
| Current | 16A to 32A | |
| Frequency | 50/60Hz | |
| Output | Rated power | 7KW / 11KW / 22KW |
| Voltage | 120V-240V / 380V-400V | |
| Current | 16A to 32A | |
| Function | Starting mode | Plug and charge, remote reservation |
| Display | LED, LCD 4.3inch | |
| Network | Bluetooth / Wifi / OCPP 1.6 | |
| Protection | RCD | Type A, Type A+6, CCID20 |
| IP/IK Rating | IP55 / IK10 | |
| Insulation | ≥10ΜΩ |
The company is a high-tech enterprise focused on charging, discharging, and energy storage solutions for electric vehicles. Main products include AC EV chargers, DC EV chargers, EV charger adapters, charging cables, V2L charging cables & adapters, V2V charging cables, EV charger wallboxes, EV charging moulds, motherboards, and EV charging mainboard solutions.
We integrate R&D, independent production, OEM/ODM manufacturing, export trade, and customized hardware & software solutions. Modern production workshops ensure stable mass production and reliable quality. We are ISO9001 certified and our products comply with domestic MA and CNAS certifications, as well as EU CE, RoHS, UKCA, North American FCC, and UL certifications.
